IMT 5020 - Boom Assembly, Lower (41717147)

Chapter 4 Parts 35
Boom Assembly, Lower (41717147)
1. 51718547 LOWER CYLINDER (INCL. 19) (WAS
3C210010)
1
2. 52717143 LOWER BOOM WELDMENT 1
3. 60120124 WEAR PAD 4
4. 72060293 CAP SCREW 5/16-24x1.00 8
5. 72063050 WASHER 5/16 LOCK 8
6. 72063002 WASHER 5/16 FLAT 8
7. 70034381 SUPPORT 2
8. 72062104 NUT 1/4-20 HEX NYLOC ZINC 2
9. 72063005 WASHER 1/2 FLAT 4
10. 60105544 PLATE-ANGLE PLASTIC 2
11 72063003 WASHER 3/8 FLAT 2
12 72062103 NUT 3/8-16 HEX NYLOC ZINC 2
13 52714976 PIN TYPE II 1.5x9.31 2
14 52715266 PIN TYPE II 1.5x8.31 1
15 72060793 CAP SCREW 1/2-13x1.00 3
16 72063053 WASHER 1/2 LOCK 3
17 72053508 ZERK-NPT .12 2
18 70034382 CAP-GREASE PRO 20 4
19. 72053507 ZERK STR THD .25-.28 2REF
REV. B 20040428
