26 5020 Parts & Specifications Manual Part # 99901218
Gear Rotator (71056543)
1. 70056527 ROTATION BEARING 1
2. 70395074 O-RING 1
3. 70395076 SEAL 2
4. 70145786 SNAP RING 1
5. 70055271 BEARING-CONE 2
6. 70055281 BEARING-CUP 2
7. 70145501 BEARING RETAINER 1
8. 70056550 WORM 1
9. 70145787 HOUSING 1
10. 72601734 CAP SCR 3/8-16X1-1/4 SH 4
11. 72601733 CAP SCR 1/2-13X1-1/4 FERRY 4
12. 73145506 SHIM .005THK 2
13. 73145505 SHIM .015THK 2
14. 73145504 SHIM .030THK 2
15. 76395075 GASKET 1
16. 72533604 PLUG 1
17. 72661504 PIN 3/8X1 2
18. 72601751 CAP SCR 5/8-11X2-3/4 HHGR8 23
19. 72063219 WASHER 5/8 FLAT HARD 23
20. 72533605 ZERK 2
21. 72533439 VENT PLUG 2
REV. B 20031029
WARNING
Any time the gear-bearing bolts have been removed, they must be replaced with new bolts of
identical grade and size. Failure to replace gear-bearing bolts may result in bolt failure due to
metal fatigue causing death or serious injury.
