IMT 5020 Parts & Specifications

Chapter 4 Parts 33
70570501 Drawing
19
1
2
3
5
4
6
8
11
7
8
9
12 REF
15
16
18
13
14
15
12
6
20
17
12
12 REF
18 2 REF
1 #17 (REF) OIL BRAKE DETAIL
HYD END W/O MOTOR
IF SPECIFIED
1 BRAKE TORQUE SETTING - 8 FT-LB AT WORM INPUT
2. DO NOT PAINT
WINCH SPECIFICATIONS
GEAR RATIO 31:1
OUTPUT TORQUE 19,800 IN-LB
MAXIMUM INPUT TORQUE 1,161 IN-LB
MAXIMUM INPUT SPEED 400 RPM
INSTALLED WEIGHT 41 LB
LUBRICATION EP140 (1 U.S. PINT)
