IMT 5020 Parts & Specifications

42 5020 Parts & Specifications Manual Part # 99901218
Boom Assembly, Extension, Flip-Sheave 20'
(41714691)
1. 3B313960 EXT CYLINDER 1
2. 52714686 EXT BOOM-1ST STG 1
3. 52714689 EXT BOOM-MANUAL 1
4. 60030189 WEAR PAD 1
5. 73733171 LOCK PIN W/HAIRPIN 1
6. 70034381 CORD GUIDE 2
7. 72063049 WASHER 1/4 LOCK 2
8. 72060006 CAP SCR 1/4-20X1-1/2 HHGR5 2
9. 60121174 STOP BLOCK 1
10. 72601750 CAP SCR 3/8-16X1/2 SHBTNHD 2
11. 72063005 WASHER 1/2 FLAT 4
12. 72601757 STUD 1/2-13X2 NC GR5 STL 4
13. 60121888 STOP BLOCK 1
14. 72601043 CAP SCR 3/8-16x3/4 FLTHDSOC 2
15. 72062080 NUT 1/2-13 HEX 4
REV. C 20040317
NOTE
