IMT 5020 Parts & Specifications

7
In This Chapter
General Specifications .............................................. 7
Performance Characteristics ..................................... 8
System Specifications ............................................... 9
Geometric Configuration, 5020 ................................. 11
Capacity Chart, 5020................................................. 12
General Specifications
GENERAL SPECIFICATIONS
CRANE RATING * 50,000 ft-lb (6.92 ton-meters)
REACH (from centerline of rotation) 20'-0" (6.10 m)
HYDRAULIC EXTENSIONS (2) 60" (152.4 cm)
MANUAL EXTENSION 48" (121.9 cm)
LIFTING HEIGHT (from base of crane) 21'-11" (6.68 m)
CRANE WEIGHT 1625 lb (737 kg)
OUTRIGGER SPAN (required option)
- Crane Side from Centerline of Chassis
- Opposite Crane Side from Centerline of
Chassis
90" (228.6 cm)
48" (121.9 cm)
STORAGE HEIGHT (crane only) 35" (88.9 cm)
MOUNTING SPACE REQUIRED (crane
base)
20" x 21" (50.8 cm x 53.3 cm)
OPTIMUM PUMP CAPACITY (PTO
Driven)
10 U.S. GPM (38.8 liters/minute)
SYSTEM OPERATING PRESSURE 3000 psi (207 bar)
LOWER BOOM CYLINDER 4-1/2" bore; 22-1/2" stroke (11.4 cm bore; 57.29 cm
stroke)
EXTENSION BOOM CYLINDER 2-1/2" bore; 60" stroke (6.4 cm bore; 152.4 cm
stroke)
HORIZONTAL CENTER OF GRAVITY
(from centerline of rotation)
36.25" (96.5 cm)
VERTICAL CENTER OF GRAVITY (from
bottom of crane base)
21" (50.8 cm)
TIE-DOWN BOLT PATTERN (on center) 14-3/4" x 14-3/4" (37.5 cm x 37.5 cm)
ROTATIONAL TORQUE 9000 ft-lb (1.2 ton-m)
C HAPTER 2
Specifications
