IMT 5020 - SECTION 3: REPAIR

Chapter 4 Parts 47
Hydraulic Kit, Tethered Remote (91715636) &
Radio Remote (91715571)
TETHERED (91715636)
1. 73734494 VALVEBANK (INCL:6,7,22) (was 73733395) 1
2. 72062104 NUT 1/4-20 LOCK 4
3. 72060005 CAP SCR 1/4-20X1-1/4 HHGR5 4
4. 72063001 WASHER 1/4 WRT 4
5. 51715640 HOSE/ADPTR KIT(INCL:8-21,23,24) 1
6. 72533425 ADAPTER #4MFACE #8MSTR 7REF
7. 72533162 ELBOW #8MSTR #8MFACE 90° 2REF
8. 51395142 HOSE YX .25X20 #4#6 2REF
9. 51395182 HOSE BBX .50X39 #8#8 1REF
10. 51395557 HOSE BBX .25X34.5 #4#4 1REF
11. 51395145 HOSE BBX .25X46.5 #4#4 1REF
12. 51395146 HOSE BBX .25X46.5 #6#4 1REF
13. 51394705 HOSE BBX .25X31 #4#4 2REF
14. 51395147 HOSE BBX .25X19.5 #4#6 2REF
15. 51394790 HOSE BBX .50X31 #8#8 2REF
16. 72533296 ADAPTER #6MFACE #10MSTR 4REF
17. 72533337 ADAPTER #4MFACE #6MSTR 1REF
18. 72533533 ADAPTER #4MFACE #8MSTR 1REF
19. 72533417 ELBOW #8MSTR #6MFACE 45° 1REF
20. 72533540 SWIVEL #4#4 FACE 90° 2REF
21. 72534368 SWIVEL, OHSE #8FACE #8JIC 2REF
22. 72533166 ADAPTER #8MFACE #8MSTR 1REF
23. 72533423 ADAPTER #8MFACE #6MSTR 1REF
REV. E 20100615
RADIO (91715571)
1. 73734530 VALVEBANK (INCL:6,7) (WAS 73733941) 1
2. 72062104 NUT 1/4-20 LOCK 4
3. 72060005 CAP SCR 1/4-20X1-1/4 HHGR5 4
4. 72063001 WASHER 1/4 WRT 4
5. 51714974 HOSE/ADAPTER KIT (INCL:8-22) 1
6. 72533425 ADAPTER #4MFACE #8MSTR 8REF
7. 72533162 ELBOW #8MSTR #8MFACE 90° 2REF
8. 51395142 HOSE YX .25X20 #4#6 2REF
9. 51395143 HOSE BBX .25X30.5 #4#4 1REF
10. 51395144 HOSE BBX .25X27.5 #4#4 1REF
11. 51395145 HOSE BBX .25X46.5 #4#4 1REF
12. 51395146 HOSE BBX .25X46.5 #6#4 1REF
13. 51394705 HOSE BBX .25X31 #4#4 2REF
14. 51395147 HOSE BBX .25X19.5 #4#6 2REF
15. 51394790 HOSE BBX .50X31 #8#8 2REF
16. 72533296 ADPTR #6MFACE #10MSTR 4REF
17. 72533376 ADAPTER #4MFACE #4MSTR 2REF
18. 72533533 ADAPTER #4MFACE #8MSTR 1REF
19. 72533417 ELBOW #8MSTR #6MFACE 45° 1REF
20. 72533540 SWIVEL #4#4 FACE 90° 2REF
21. 72534368 SWIVEL, HOSE #8FACE #8JIC 2REF
REV. C 20100615
