IMT 5020 Parts & Specifications

Chapter 4 Parts 39
Cylinder, Lower (3C210010) (Thru 6-04)
1. 4C210010 CASE ASM (PART OF 28, INCL. 6 & 7) 1REF
2. 4G035980 ROD ASM (INCL: 6&7) 1REF
3. 6HD45022 HEAD (PART OF 28) 1REF
4. 6ID45143 PISTON (PART OF 28) 1REF
5. 6C150022 STOP TUBE (PART OF 28) 1REF
6. 72053507 ZERK (PART OF 1,2) 2REF
7. 7FB81215 BUSHING (PART OF 1,2) 6REF
8. 9D181823 SEAL KIT (PART OF 28, INCL. 9-18) 1REF
9. 6A025022 WAFER LOCK (PART OF 8) 1REF
10. 7R14P022 ROD WIPER (PART OF 8) 1REF
11. 7R546022 U-CUP, SEAL ROD (PART OF 8) 1REF
12. 7Q072155 O-RING 4 X 4.19 X .103 (P/O 8) 1REF
13. 7Q072346 O-RING 4.1 X 4.5 X .210 (P/O 8) 1REF
14. 7Q10P346 BACKUP RING (PART OF 8) 1REF
15. 7T61N143 LOCK RING (PART OF 8) 1REF
16. 7T66P045 PISTON SEAL (PART OF 8) 1REF
17. 7T2NX625 WEAR RING (PART OF 8) 2REF
18. 7T2N4045 WEAR RING (PART OF 8) 2REF
19. 72533186 ADPTR #6MFACE #6MSTR 4
20. 70145753 TUBE ASM 1
21. 70145927 TUBE ASM 1
22. 77041561 PRESS SWITCH (PART OF 24) 1REF
23. 73540052 VALVE-CBAL (PART OF 24) 1REF
24. 73540035 VALVE-CBAL (INC. 22,23) 1
25. 72062109 NUT 5/16-18 HEX NYLOC 2
26. 72063002 WASHER 5/16 FLAT 4
27. 72060037 CAP SCR 5/16-18X 4.00 HHGR5 2
28. 3C210010A CYLINDER (INCL. 5-8) 1
REV. A 20040310

IMT 5020 Specifications

General

Brand	IMT
Model	5020
Category	Construction Equipment
Language	English
