Chapter 4 Parts 37
Lower Cylinder (51718547) (Eff. 6-29-04)
1. 4C210010 CASE ASSEMBLY (INCL. 15) 1
2. 51718547A CYLINDER (INCL. 1,3,4,6,7,9,14) 1
3. 51744132 SEAL KIT (INCL. 4,7,22-29) 1
4. 52718385 ROD ASM (INCL. 15) 1
5. 60125699 PIN 1REF
6. 60125922 STOP TUBE 1
7. 60125926 PISTON 1
8. 6A025022 WAFER LOCK 1REF
9. 6HD45022 HEAD 1
10. 70145753 TUBE ASM 1
11. 70145927 TUBE ASM 1
12. 72060037 CAP SCR .31-18X 4.00 HH GR5 Z 2
13. 72062109 NUT .31-18 HEX NYLOCK 2
14. 72062305 COLLAR-LOCK 1-1/2-12 X 2.375 X .563 1
15. 72063002 WASHER .31 FLAT 4
16. 72503507 ZERK-STR THD .25-28 2REF
17. 72533186 ADPTR-#6 M FACE/ #6 M STR 4
18. 72533603 PLUG- 7/16 STR HOL HEX STL 1
19. 73540035 VALVE-CBAL 1
20. 73540052 VALVE - CBAL 1
21. 77041561 PRESSURE SWITCH 1
22. 7BF81215 BUSHING-STL 1.50 PIN X 1.25 LG 6REF
23. 7Q072128 O RING 1.487X 1.693X 0.103 70 1REF
24. 7Q072155 O-RING - 4 X 4.19 0.09 70 1REF
25. 7Q072346 O-RING - 4.12 X 4.5 0.19 70 1REF
26. 7Q10P346 BACKUP RING-4.12 ID X 4.50 OD 1REF
27. 7R14P022 ROD WIPER-TYPE D 2.25 ROD 1REF
28. 7R546022 U-CUP LOADED 2.25X2.75X.38 "B 1REF
29. 7T2N4045 WEAR RING - PISTON 4.50 O.D. X .50 W 2REF
30. 7T2NX625 WEAR RING-ROD 2.25 IDX0.75 2REF
31. 7T66P045 PISTON SEAL-DYNAMIC 1REF
NEW 20040428
