IMT 5020 Parts & Specifications

52 5020 Parts & Specifications Manual Part # 99901218
73733395 Drawing
23
(Torque
to 55 ft-lb
lubricated)
UP OUT OUT CW
DN IN DN CCW
4
WINCH EXT LOWER ROT
Plastic
Clamp
18,19 TYP 3
(Use Loctite 242)
17
PWM%
MIN
POWER
Power Indicator LED:
Off = Blank
On = Red Light
9,11,12
P5 P6 P7 P8
P14 P13 P12 P11
P15
WINCH
UP DN
EXTENSION
IN OUT
LOWER
UP DN
ROTATION
CCW CW
P5 P14 P6 P13 P7 P12 P8 P11
P15
P
T
LEFT VIEW
RIGHT VIEW
Red = Off, zero % trigger
Green = Full on, 100% trigger
Shortened coil or other will show
as red with 100% trigger.
PERCENT OF SIGNAL INDICATOR COLOR-CHANGING LED:
24
1
5
3
25
13,14,20
METAL CLAMP
23 REF
(Not shown
in all views)
22(7)
10
2
16
23
