Chapter 4 Parts
63
Electrical Schematic, Tethered Remote
(99900855)
1. 51713182
HANDLE
ASM
1
2. 60119299
BRACKET
1
3. 77044645
NUT-DEUTSCH
CONNECTOR
1
4.
77044646
LOCK WASHER -DTSCH CONN
1
5.
51713343
CABLE ASM 14GA/2 WIRE
1
6.
70034439
LOCK WIRE LEAD SEAL 8”
2
7. 77041597
HARNESS,
DUAL-PRESS.
1
REV. L 200402
10
64
66
