58 5020 Parts & Specifications Manual Part # 99901218
Wiring Chart (70733394)
TERM: 0462-201-16141 SEAL: - CAVITY PLUG: 114017
CAVITY COLOR GA. PRINT LABEL TO CON-SPLC CAVITY
A WHT 18 ROT J11B TO J11 B
B WHT 18 EXT J13B TO J13 B
C WHT 18 WIN J5B TO J5 B
D WHT 18 WIN J14B TO J14 B
E WHT 18 J4A REF TO J4 A
F WHT 18 EXT J6B TO J6 B
G WHT 16 P2 6 ENG START TO P2 6
H WHT 18 P3B SIG COMM TO P3 B
I - - - TO - -
J WHT 18 P2 4 SPD RLA TO P2 4
K WHT 18 ROT J8B TO J8 B
L WHT 16 PENDANT PWR(+) TO SPL A -
M WHT 18 P2 2 KILL RLA TO P2 2
N WHT 18 LOWER J7B TO J7 B
O WHT 16 P1 O SOL WPR TO P2 1
P WHT 18 LOWER J12B TO J12 B
Q - - - TO - -
R WHT 18 J4B VOLTAGE TO J4 B
S WHT 18 P1S ON H TO SPL D -
T WHT 16 P2 5 COMPR TO P2 5
U WHT 16 WNSPD P16B TO P16 B
V - - - - - -
W - - - - - -
LOCATOR CODE: P2 DEUTSCH: DT04-8PA
TERM: 1060-16-0122 WEDGE: W8P CAVITY PLUG: 114017
CAVITY COLOR GA. PRINT LABEL TO CON-SPLC CAVITY
1 WHT 16 P1 SOL PWR TO P1 -
2 WHT 18 P2 2 KILL RLA TO P1 M
3 WHT 16 P2 3 BAT (-) TO SPL B -
4 WHT 18 P2 4 SPD RLA TO P1 J
5 WHT 16 P2 5 COMPRESSOR TO P1 T
6 WHT 16 P2 6 ENG START TO P1 G
7 WHT 16 P2 7 IGN SOL TO SPL A -
8 - - - TO - -
LOCATOR CODE: P3 PACKARD: 12015797
TERM: 12089188 SEAL: 12015323
CAVITY COLOR GA. PRINT LABEL TO CON-SPLC CAVITY
A WHT 16 P3A POWER (+) TO SPL A -
B WHT 18 P3B SIG COMM TO P1 H
C WHT 16 PRPVLV (-) TO J15 A
D WHT 16 PRPVLV (+) TO J15 B
