IMT 5020 Parts & Specifications

Chapter 4 Parts 61
Wiring Chart (70733394)
- WHT 16 RELAY GND TO R1 87
- WHT 16 P2 3 BAT (-) TO P2 3
- WHT 16 J4D PWR COM TO J4 D
- WHT 16 ROT J11A TO J11 A
- WHT 16 LOWER J12A TO J12 A
- WHT 16 EXT J6A TO J6 A
- WHT 16 ROT J8A TO J8 A
- WHT 16 ATB J9A TO J9 A
LOCATOR CODE: R1
RELAY SOCKET: PACKARD 12065685, 12052834
TERM:
12066614
RELAY: HELLA 87411 (SEALED)
CAVITY COLOR GA. PRINT LABEL TO CON-SPLC CAVITY
30 WHT 16 ATB & OPRES GRD TO SPL C -
87 WHT 16 RELAY GRD TO SPL B -
87A - - - TO - -
86 WHT 16 RELAY PWR (+) TO SPL D -
85 WHT 16 OPSI P10A TO P10 A
LOCATOR CODE: - SPLICE C
CAVITY COLOR GA. PRINT LABEL TO CON-SPLC CAVITY
- WHT 16 J7A LOWER TO J7 A
- WHT 16 ATB & OPRES GND TO R1 30
- WHT 16 EXT J13A TO J13 A
- WHT 16 WINCH J14A TO J14 A
- WHT 16 WNSPD P16A TO P16 A
LOCATOR CODE: - SPLICE D
CAVITY COLOR GA. PRINT LABEL TO CON-SPLC CAVITY
- WHT 18 P1S ON H TO P1 S
- WHT 16 RELAY PWR (+) TO R1 86
- WHT 18 J4C ON H TO J4 C
CIRCUIT CROSS REFERENCE FOR 3000 STATIONARY MOUNT CRANE
LOCATOR CODE PRINT LABEL 3000 FUNCTION
P1 B EXT J13B INNER BOOM DOWN
P1 C WINCH J5A EXT. BOOM IN
P1 D WINCH J14B EXT. BOOM OUT
P1 F EXT J6B INNER BOOM UP
P1 N LOWER J7B OUTER BOOM UP
P1 P LOWER J12B OUTER BOOM DOWN
J5 A WINCH J5B EXTENSION BOOM IN
