IMT 5020 Parts & Specifications

Chapter 4 Parts 67
Handle Assembly, Tethered Remote Kit (51713182) (see "Handle Assembly, Tethered
Remote (51713182)" on page 65)
WIRE FUNCTIONS
SOLID/STRIPE FUNCTION
A YEL/BLK ROT CW
B ORN/BLK EXT OUT
C BLU/BLK WINCH DN
D RED/BLK WINCH UP
E ORN/RED -
F BRN EXT IN
G BRN/RED ENG START
H BLU/RED -
J BLK/RED ENG SPEED
K BRN/BLK ROT CCW
L RED POWER
M BLU ENG STOP
N ORN LOWER DN
O BLK/ORN SOL POWER
P YEL LOWER UP
Q BRN/BLU -
R YEL/RED -
S BLK CRANE
T BLK/BLU CPRSR
U RED/BLU OPTION
V BLU/ORN -
W ORN/BLU -
X YEL/BLU -
- RED/RON -
