10.3 Bus module
On the USB stick enclosed with the device and the bus module BM1000 you will find
further files on the subject of bus modules. This also includes the GSD file for
PROFIBUS, which is located in the “..\Manuals\Interface Description“ folder.
For the different bus modules from INFICON see also “Accessories and spare parts
[}126]“.
10.3.1 Creating a connection between the device and the bus
module
To establish the connection between the leak detector and the bus module, proceed
as follows:
1 Switch off the leak detector.
2 Connect the INFICON bus module via a data cable to the LD socket of the
device, see “Connections for accessories and control signals [}31]“.
3 Switch on the leak detector.
4 > Setup > Accessories > Device selection
5 Select the "Bus module" as device.
6 Confirm with .
10.3.2 Setting a bus module address
You can set the setpoint for the field bus address. With PROFIBUS® this is the node
address. DeviceNet is the MAC ID.
This setting is irrelevant for Profinet and EtherNet/IP.
1 > Setup > Accessories > Bus module
2 Enter the desired address in the "Bus module address" field.
3 Confirm with .
ð The value set is first carried over when restarting the leak detector. To do this,
switch the power supply off and back on.
