Intel 100 Series User Manual

Intel
®
Omni-Path Fabric Switches
May 2016 Installation Guide
Doc. No.: H76456Rev 3.0US 69
Omni-Path Switches
2.8.2.5 SEEB Module
2.8.2.5.1 RJ45 LEDs
The RJ45 connectors have two LEDs, Link and Speed. The Speed LED is Green when
a 100Mbps link is connected. The Link LED is Amber when an Ethernet link has been
established, and blinking when the link is active.
2.8.2.5.2 MRL Active
The MRL Active LED is Green when the mechanical release latch (MRL) thumbscrew is
secured to the serial, Ethernet, Chassis EEPROM Board (SEEB) and a Management
Module is installed in the front of the chassis.
Figure 56. SEEB Module LEDs

Intel 100 Series Specifications

General

Product Type	Switch
Port Speed	10/100/1000 Mbps
Switching Capacity	Varies by model
Forwarding Rate	Varies by model
MAC Address Table	Varies by model
Jumbo Frame Support	Yes
Dimensions	Varies by model
Weight	Varies by model
Number of Ports	Varies (typically 8, 16, 24, 48)
Port Count	Varies by model
Data Transfer Rate	1 Gbps
