Table 32. Output File Types
Programming File Type Extension Description
JTAG Indirect Configuration File
.jic The .jic enables serial flash programming via Intel FPGA JTAG pins. This file type is available
only for ASx4 configuration. A newly populated board using the ASx4 configuration scheme
requires initial SDM firmware programming. The helper SOF image provides the required SDM
firmware.
You initially use the JTAG cable to load a SDM Helper SOF into the Intel Agilex device. The SDM
can then load the flash device with the Intel Agilex design.
Raw Programming Data File
.rpd
Stores data for configuration with a third-party programming hardware. You generate Raw
Programming Data Files from a .pof or .sof.
The .rpd file is a subset of a .pof or .jic that includes only device-specific binary programming
data for Active Serial configuration scheme with quad SPI configuration devices and remote
system update.
Related Information
Programming Serial Flash Devices using the AS Interface on page 110
