Intel Agilex Series

Figure 68. RSU Image Layout in Flash : SDM Perspective
In this figure:
• Each of the Decision Firmware copies point to the Factory Image and both Pointer Block 0 and Pointer Block 1.
• Both Pointer Block 0 and Pointer Block 1 point to Application Images.
Decision Firmware
Decision Firmware
Decision Firmware
Decision Firmware
Pointer Block 0
Pointer Block 1
Factory Image
Application Image 1
Application Image 2
Higher Addresses
Base
Decision Firmware Data
Can be updated only through an update image
Can be written directly
