Intel Agilex Series

Document Version Intel Quartus
Prime Version
Changes
•
Removed CONF_DONE configuration function from the Required Configuration Signals for the AS Configuration Scheme
table.
•
Added .rpd programming file in the Output File Types table in the AS Configuration Scheme Hardware Components and
File Types.
• Revised JTAG Configuration
• Removed QSF Assignment for AS topic.
• Added video describing reset importance in the Including the Reset Release Intel FPGA IP in Your Design.
• Revised attention note in Understanding the Reset Release IP Requirement.
• Added important note about the RSU SDM Command Use Case in Operation Commands.
• Revised Command List and Description table. Updated description for:
—
CONFIG_STATUS
—
RSU_STATUS
•
Added new topic: Generating the Initial RSU Image Using .rbf Files
• Corrected minor errors and spelling mistakes.
2021.06.21 21.2 Made the following changes:
• Added a CvP-related note in the Intel Agilex Configuration Overview.
• Revised block diagram descriptions in the Intel Agilex Configuration Architecture.
• Revised Intel Agilex Configuration Timing Diagram.
— Added a note in the Reconfiguration Timing section.
— Re-ordered sections for clarity.
• Revised Intel Agilex Configuration Flow Diagram section.
— Renamed Power Up section to Power-On to align the description with figure.
— Merged Configuration Start and Configuration Pass sections into the FPGA Configuration section.
— Renamed Configuration Error section to Failed FPGA Configuration.
— Minor re-ordered sections for clarity.
— Removed JTAG Configuration section. Reposition the existing JTAG configuration note.
— Moved device response content to a new section: Device Response to Configuration and Reset Events.
•
Removed DATA UNLOCK signal from the Available SDM I/O Pin Assignments for Configuration Signals that Do Not Use
Dedicated SDM I/O Pins. DATA UNLOCK is not available for Intel Agilex devices.
• Revised text and figure in SDM I/O Pins for Power Management and SmartVID
•
Revised OSC_CLK_1 requirements in OSC_CLK_1 Clock Input
• Added new topic: Intel Agilex Configuration Time Estimation
• Added new PFL II IP-related topics:
— PFL II IP Recommended Constraints for Other Input Pins
— PFL II IP Recommended Constraints for Other Output Pins
continued...
