Intel Agilex Series

Document Version Intel Quartus
Prime Version
Changes
•
Corrected T
ext_delay
maximum value for OSC_CLK_1 configuration clock source at 166 MHz from 15 ns to 13.5 ns in the
t
ext_delay
as a Function of AS_CLK Frequency table.
• Revised AS_CLK topic:
—
Updated OS_CLK_1 description in the Supported Configuration Clock Source and AS_CLK Frequencies in Intel Agilex
Devices table. Added table's description.
—
Added note to clarify configuration behavior for invalid AS_CLK setting.
• Corrected address in the Debugging Guidelines for the AS Configuration Scheme. The firmware load should start from
addresses 0, 512k, 1024k, and 1536k.
• Revised the steps for image update in the Updates with the Factory Update Image section.
• Revised Command List and Description table. Updated description for:
—
RSU_STATUS
—
QSPI_OPEN
—
QSPI_SET_CS
—
QSPI_ERASE
•
Revised RSU Image Layout in Flash - SDM Perspective. Updated max_retry parameter value description.
•
Revised step 2 in the Command Sequence To Perform Quad SPI Operations. The QSPI_SET_CS* command is optional for
the AS x4 configuration and mandatory for the JTAG configuration scheme.
• Added new topic: Firmware Version Information
• Clarified usage of Use relative address option in the Application Image Layout and Generating an Application Image
sections.
• Added new video guide about debugging SDM-related configuration issues in Intel Agilex Debugging Guide.
• Updated the following figures and diagrams:
— Intel Agilex Configuration Interfaces
— Power-On, Configuration, and Reconfiguration Timing Diagram
— Recoverable Error during Reconfiguration Timing Diagram
— Intel Agilex FPGA Configuration Flow
— SDM I/O pins selection in the Specifying Optional Configuration Pins section
— Configuration Pin Selection in the Intel Quartus Prime Pro Edition Software
— Dual-purpose pins selection in the Enabling Dual-Purpose Pins section
— Specifying the Slave Device Type for Power Management and VID
— Specifying the Page Command Setting
— Configuration clock source selection in the Setting Configuration Clock Source section
— AS configuration scheme setting in the Active Serial Configuration Software Settings section
• Corrected minor errors and spelling mistakes.
2021.03.29
21.1 Made the following changes:
continued...
