Example 11. Set input delay to PFL II IP input pins
Example below sets the input delay for the pfl_flash_access_granted pin.
• You don't have to constraint the path when you use the device arbiter logic to control the pin,
• You don't have to constraint the path when not using the device arbiter logic or the external processor to control the pin
and you loopback the pfl_flash_access_request signal to the pfl_flash_access_granted pin.
•
You can constraint the path when a processor or an external device controls the pfl_flash_access_granted pin.
set_input_delay -clock {clk_50m_sysmax} -max [<pfl_flash_access_granted_tco_max> +
<pfl_flash_access_granted_tracemax>] [get_ports {pfl_flash_access_granted}]
set_input_delay -clock {clk_50m_sysmax} -min [<pfl_flash_access_granted_tco_min> +
<pfl_flash_access_granted_tracemin>] [get_ports {pfl_flash_access_granted}]
Example 12.
Set a false path for fpga_pgm[] input pin
You can set a false path to quasi-static signals such as reset and configuration signals (fpga_conf_done, fpga_nstatus)
that are stable for a long periods of time.
set_false_path -from [get_ports {fpga_pgm[]}] -to *
Example 13.
Set input delay to pfl_nreconfigure input pin
If you use the external component to drive this pin, you must set the input delay path to drive the pfl_nreconfigure pin.
set_input_delay -clock {clk_50m_sysmax} -max [<pfl_nreconfigure_tco_max> + <pfl_nreconfigure_tracemax>] \
[get_ports {pfl_nreconfigure}]
set_input_delay -clock {clk_50m_sysmax} -min [<pfl_nreconfigure_tco_min> + <pfl_nreconfigure_tracemin>] \
[get_ports {pfl_nreconfigure}]
Example 14.
Set input delay to pfl_reset_watchdog pin
If you use the external component to drive this pin, you must set the input delay path to drive the pfl_reset_watchdog
pin.
set_input_delay -clock {clk_50m_sysmax} -max [$pfl_reset_watchdog_tco_max + $pfl_reset_watchdog_tracemax] \
[get_ports {pfl_nreconfigure}]
set_input_delay -clock {clk_50m_sysmax} -min [$pfl_reset_watchdog_tco_min + $pfl_reset_watchdog_tracemin] \
[get_ports {pfl_nreconfigure}]
