3.1.7.4.5. PFL II IP Recommended Constraints for Other Output Pins
Example 15. Set output delay to PFL II IP output pins
Example below sets the output delay for the pfl_flash_access_request output pin.
• You don't have to constraint the path when this signal feeds arbiter logic or device tristate logic,
•
You don't have to constraint the path when this signal feeds the pfl_flash_access_granted input pin while not using
the device arbiter logic or the external processor.
• You can constraint the path when this signal feeds the processor or an external device controls.
set_output_delay -add_delay -clock [get_clocks { clk_50m_sysmax }] \
-max $flash_access_request_tracemax [get_ports {pfl_flash_access_request}]
set_output_delay -add_delay -clock [get_clocks { clk_50m_sysmax }] \
-min $flash_access_request_tracemin [get_ports {pfl_flash_access_request}]
Example 16.
Set output delay to flash_nreset output pin
The flash_nreset output pin is available in Burst mode only.
set_output_delay -add_delay -max -clock [get_clocks { FLASH_CLK }] $flash_out_max_dly [get_ports {flash_nreset}]
set_output_delay -add_delay -min -clock [get_clocks { FLASH_CLK }] $flash_out_min_dly [get_ports {flash_nreset}]
Example 17.
Set a false path for fpga_nconfig output pin
You can set the fpga_nconfig output pin to a false path since the nCONFIG is an asynchronous input pin..
set_false_path -from [get_ports {fpga_nconfig}] -to *
Example 18.
Set output delay to pfl_watchdog_error output pin
• You don't have to constraint the path when the signal feeds the internal logic.
• You can constraint the path when signal feeds an external host.
set_output_delay -add_delay -clock [get_clocks { clk_50m_sysmax }] \
-max $pfl_watchdog_error_tracemax [get_ports {pfl_watchdog_error}]
set_output_delay -add_delay -clock [get_clocks { clk_50m_sysmax }] \
-min $pfl_watchdog_error_tracemin [get_ports {pfl_watchdog_error}]
