Cable Handling and Bend Radius
• Intel
®
Omni-Path Copper Cable 100 Series:
— Recommended minimum bend radius is >69mm
• Intel
®
Omni-Path Active Optical Cable 100 Series:
— Recommended minimum bend radius is >105 mm within 100 mm of either
cable end module, and >60 mm on the rest of the cable
Table 1. Cable Bend Radius Guidelines
Intel
®
Omni-Path Copper Cable 100 Series
American Wire Gauge (AWG) Size Cable Bend Radius
26 >69 mm
30 >66 mm
Intel
®
Omni-Path Active Optical Cable 100 Series
Gauge Bend Radius
Optical >105 mm within 100 mm of either cable end module
>60 mm on the rest of the cable
Figure 3. Copper Cable Bend Radius
