where -h <ipaddress> is the new default gateway IP address in dotted decimal
format.
6. The changes are effective immediately.
Updating the Management Module IP Addresses in a Director
Class Redundant Management Configuration
Each management module (MM) must have a unique IP address that is different than
the chassis IP address of the switch. A redundantly-managed switch will have multiple,
unique IP addresses. The default IP addresses are:
• Chassis: 192.168.100.9
• Management Module(s): 192.168.100.10
It is necessary for each management module to have a unique IP address for the
following reasons:
• Unique IP addresses are used when sending syslog messages from a management
module to a syslog server.
• Gives the user the ability to ping each management module separately.
• If the IP addresses are not unique, collisions occur, causing IP operations to fail.
NOTE
All management modules are individually tested and configured with the default IP
address of 192.168.100.10. In order to avoid an address conflict, be certain to change
the default IP address of each MM after inserting it into the chassis.
NOTE
Make sure when updating the MM IP, only 1 module is inserted into the chassis at a
time. Repeat this procedure for the second MM.
To update the IP address on a management module, do the following:
1. Insert a MM into the chassis.
2. Connect the MM via the USB port to a serial console software (e.g., Putty or
Teraterm).
3. Reset/apply power to the MM.
4.
When the system displays image1 or image2, press the SPACEBAR to interrupt
the auto load sequence before the counter expires (within 5 seconds).
5. Enter moduleip <IP ADDRESS> in dotted decimal format and press ENTER.
6. To update the module netmask address enter netmask <ADDRESS> in
hexadecimal format and press ENTER.
7. To update the module gateway address enter gateway <ADDRESS> in dotted
decimal format and press ENTER.
8. At the boot prompt, reboot the MM.
Component LEDs
2.7.3
2.8
Installation—Intel
®
Omni-Path Fabric
Intel
®
Omni-Path Fabric Switches Hardware
June 2019 Installation Guide
Doc. No.: H76456, Rev.: 10.0 75
