You can check the progress of the update with the CLI command
showLastBcFwRetCode -all. The system returns information similar to the
following:
Edge-> showLastBcFwRetCode -all
Module Board Controller Firmware Last Exit Code: 3: In Progress
Edge-> showLastBcFwRetCode -all
Module Board Controller Firmware Last Exit Code: 0: Success
Proceed to Step 3.
3. Reboot the switch.
4. Verify the version of the BCFW and BIOS by running the CLI commands
bcfwversion and biosversion. The system should return information similar
to the following:
Board Controller Firmware Version: CGBCP429
System BIOS Version: QA3ER962
Updating Director Class Switches
Update the BCFW and BIOS on Director Class switches (DCS) using the instructions in
Performing the Upgrade on page 88.
NOTE
The instructions upgrade both the Master and Slave MM.
Performing the Upgrade
1. At the master MM prompt, enter the following command to update the master and
slave: sftp> put QA3ER962.q7.spkg A:/firmware/bios.pkg
The system returns information similar to the following:
Uploading QA3ER962.q7.spkg to /firmware/A:/firmware/bios.pkg
QA3ER962.q7.spkg
100% 8193KB 12.4MB/s 00:00
You can check the progress of the update with the CLI command
showLastBiosRetCode -all. The system returns information similar to the
following:
MasterM201-> showLastBiosRetCode -all
M201 System BIOS Last Exit Code: 3: In Progress
M202 System BIOS Last Exit Code: 0: Success
MasterM201-> showLastBiosRetCode -all
M201 System BIOS Last Exit Code: 0: Success
M202 System BIOS Last Exit Code: 0: Success
NOTE
DO NOT REBOOT AT THIS TIME. Wait until both the BCFW (via bcfwupdate) and
the BIOS (via biosupdate; see Step 2) have been updated, then reboot.
Proceed to Step 2.
