Intel Omni-Path Switch 100 Series - Installing the Switch Fascia; Clamp over Rail Post; Reattach the Rail Post

Figure 15. Clamp over Rail Post
4. Reattach the rail post, which locks the clamp into place.
Figure 16. Reattach the Rail Post
Installing the Switch Fascia
The Edge switch fascia guards against ESD as well as accidental contact with the fans
and power supplies.
