Figure E-37. 1U Heatsink, Nut Collar (Reference Only)
A A
13
4
5678
B
C
D
A
123
4
5678
B
C
D
A
B
2200 MISSION COLLEGE BLVD.
P.O. BOX 58119
SANTA CLARA, CA 95052-8119
R
0.2 A
0.7±0.05
5.2 0.05
.05 B
7.8
0.05
A
H94875 1 D
DWG. NO SHT. REV
SHEET 1 OF 1
DO NOT SCALE DRAWING
SCALE: 25
DH94875D
REV
DRAWING NUMBER
SIZE
SKT-P, HEATSINK COLLAR
TITLE
DEPARTMENT
SEE NOTESSEE NOTES
FINISHMATERIAL
DATEAPPROVED BY
-
3/8/17
DATECHECKED BY
3/8/17
DATEDRAWN BY
3/8/17
DATEDESIGNED BY
DIMENSIONS ARE IN MILLIMETERS.
THIRD ANGLE PROJECTION
PARTS LIST
DESCRIPTIONPART NUMBER
ITEM NO
QTY
SKT-P, HEATSINK NUT COLLAR (BOTTOMSIDE)H94875-004TOP
REVISION HISTORY
ZONE REV DESCRIPTION DATE APPR
- A PRELIMINARY RELEASE 9/10/15
B4 B
1.CHANGED THE MATERIAL FROM DELRIN TO NY66 A205F.
2.ADDED CTF DIMENSION TO INNER DIAMETER
3. UPDATED NOTES 3 AND 5.
4. ROLLED DASH NUMBER FROM H94875-001 TO H94875-002.
12/15/15
D5
C5
B4
C
1. DIMENSIONS CHANGED
2. ADDED RUNOUT AND CTF TO O.D 8MM
3. ADDED DATUM B TO 1.D 5.2MM
4. ROLLED DASH NUMBER FROM H94875-002 TO H94875-003
5. MATERIAL SPEC CHANGED TO BLUE COLOR.
02/06/17
D5
B5
B3
D
1. O.D HAS CHANGED FROM 8MM TO 7.8
2.THICKNESS HAS CHANGED FROM 0.5MM TO 0.7MM
3.MATERIAL SPEC CHANGED TO COLOR: NOT SPECIFIED, HOWEVER
BLACK NOT SUGGESTED
03/08/17
NOTES; UNLESS OTHERWISE SPECIFIED:
1. REFERENCE DOCUMENTS
99-0007-001 - INTEL WORKMANSHIP STANDARD - SYSTEMS MANUFACTURING
18-1201 - INTEL ENVIRONMENTAL PRODUCT CONTENT SPECIFICATION FOR SUPPLIERS
& OUTSOURCED MANUFACTURERS (FOUND ON EHS WEBSITE -
https://supplier.intel.com/static/EHS/)
ASME Y14.5-2009 - STANDARD DIMENSION AND TOLERANCES
2. FEATURES NOT SPECIFIED ON DRAWING SHALL BE CONTROLLED BY 3D CAD DATABASE. FOR
FEATURES NOT EXPLICITLY TOLERANCED: (BASIC DIMENSIONS FROM THE 3D CAD MODEL):
3. MATERIAL: MAY USE INTEL ENGINEERING APPROVED EQUIVALENT.
ALL SUBSTANCES IN THIS PART MUST CONFORM TO INTEL ENVIRONMENTAL PRODUCT
SPECIFICATION (BS-MTN-0001).
A) NY66 A205F.
B) PIGMENT: N/A
C) COLOR: NOT SPECIFIED, HOWEVER BLACK NOT SUGGESTED
4 CRITICAL TO FUNCTION DIMENSION (CTF).
5. PART MUST COMPLY WITH INTEL WORKMANSHIP STANDARD (99-0007-001).
PART SHALL BE FREE OF OIL AND DEBRIS.
FINISH: UNSPECIFIED SURFACES MUST CONFORM WITH CLASS C REQUIREMENTS.
6 NO GATING ALLOWED ON THIS COMPONENT MATING SURFACE.
6
D
D
SECTION A-A
