Installing Above Deck Unit (ADU)
23
5. Assemble ground cable with bolt kits.
Before assembly ground
cable, tear off the
grounding hole sticker
(2 sides)
5/16"-18*1/1/4"
Hex- flange screw (2 ea),
5/16"-18 kepts k-lock,
nut (2 ea)
Ground cable
Penetrating fastener option:
For directly mounting using fasteners,
place appropriately fasteners, at the
locations circled in the below diagram
12-3/4" tapping screw
(Optional)
To Next Page
