Chapter 4 — Install Applications on the IF2 with Expanded Memory Option
58 IF2 Network Reader User Manual
About the Developer Tools
Use the Developer Tools for basic testing of your RFID system. The
Developer Tools support these features:
• General purpose input/output (GPIO) testing. For help, see the
next section.
• Sending BRI commands or BRI script files to the IF2 from an
interactive browser interface. For help, see “Send BRI Commands
and Running Scripts” on page 59.
• Editing and testing JavaScript files. For help, see “Use the
Workbench” on page 59.
Test the GPIO Interfaces
If you have external GPIO controls such as motion sensors or
indicator lamps connected to the IF2, you can use the Diagnostics
tool to test the interfaces and verify that the controls behave as
expected. Leave the controls connected to the IF2 GPIO port when
using the Diagnostics tool.
To test the GPIO interfaces
1 From the menu, click Edgeware Applications > Developer Tools
> GPIO. The GPIO screen appears.
2 Check the check box for each of the GPIO interfaces you want to
test. When you check the check box, that GPIO output will be
turned on, and its associated GPIO input is turned on.
3 Click Read and Write GPIO. The GPIO interface state is changed.
Note: To use the Developer Tools, you need to enable them. For help,
see “About the Edgeware Applications” on page 57.
