Appendix C — Setup Parameters (Fingerprint)
90 EasyCoder PD42 Printer User’s Guide
Refer to the EasyCoder E4 Direct Protocol Programmer’s Reference
Manual (P/N 1-960419-xx) for more information about the
commands, syntax, etc.
Adjust
The user can modify the Base and Stop parameters, which are
functionally similar to Start Adjust and Stop Adjust as described
under “Feed Adjust Setup” on page 90. The unit is different
however; instead of being given in dots, Base and Stop values are
defined as the distance in millimeters multiplied by 10:
• Base (mmX10)
Default value is +88, which equals a distance of 8.8 mm or
roughly 0.35 inches.
• Stop (mmX10)
Default value is +55, which equals a distance of 5.5 mm or
roughly 0.22 inches.
Feed Adjust Setup
The Feed adjust part of Setup Mode controls how much of the
media is fed out or pulled back before and/or after the actual
printing. These settings are global and will be effected regardless
of which program is run.
Start Adjust
The Start Adjust value is given as a positive or negative number of
dots. The default value is 0, which places the origin a certain
distance back from the front edge of the copy:
• A positive start adjustment means that the specified length of
media will be fed out before the printing starts. Thus, the
origin is moved further back from the forward edge of the
copy.
• A negative start adjustment means that the specified length of
media will be pulled back before the printing starts. Thus, the
origin is moved towards the forward edge of the copy.
Note: The firmware uses the front edges of labels with gaps, the
ends of detection slots, and the forward edges of black marks for
detection, all seen in relation to the feed direction.
