Appendix B — Media Specifications
74 EasyCoder PD42 Printer User’s Guide
Self-Adhesive Labels
* This is the print length limit set by memory constraints.
The Label Gap sensor must be able to detect the front edges of
the labels. It can be moved 0 to 57 mm (0 to 2.24 inches) from
the inner edge of the media.
Paper Type Setup
• Labels with Gaps
a: Media Width
Maximum: 118.0 mm 4.65 inches
Minimum: 25.0 mm 1.00 inches
b: Liner
The liner must extend evenly on both sides and not more than a total
of 1.6 mm (0.06) inches outside the face material.
c: Label Width (Excluding Liner)
Maximum: 116.4 mm 4.58 inches
Minimum: 23.8 mm 0.94 inches
d: Label Length Fingerprint IPL
8 dots/mm (203 dpi)
Maximum: 1270 mm (50 in.)* 600 mm (23 in.)
Minimum: 6 mm (0.2 in.) 6 mm (0.2 in.)
11.81 dots/mm (300 dpi)
Maximum: 558.8 mm (22 in.)* 406.4 mm (16 in.)
Minimum: 6 mm (0.2 in.) 6 mm (0.2 in.)
e: Label Gap
Maximum: 26.0 mm 1.02 inches
Minimum: 1.2 mm 0.05 inches
Recommended: 3.0 mm 0.12 inches
