Appendix D — Setup Parameters (IPL)
106 EasyCoder PD42 Printer User’s Guide
• XON/XOFF+Status
• Intermec Standard Protocol
The Intermec Printer Standard Protocol is a half-duplex protocol.
All data transmissions to the printer consist of status inquiry
(ENQ), status dump (VT), or message blocks. Each message
block starts with the Start of Text (STX) character and ends with
the End of Text (ETX) character. Each message block must be
255 characters or less, including the STX and ETX characters.
The printer responds to each status inquiry or message block
with the printer status. The host should check the printer status
before downloading a message block to the printer. ENQ causes
the printer to transmit its highest priority status, while VT
instructs the printer to transmit all status that applies in the order
of their priority. The next table lists the possible printer status in
descending priorities are
Com Setup
The parameters under the Com node control interface and
external keyboard use.
Interface
If you have an optional Parallel IEEE 1284 interface installed in
the printer, it cannot be used at the same time as the USB Device
interface. In this menu, you can choose which interface is active.
Condition Character
Buffer already full GS
Printhead raised US
Ribbon fault US
No label stock EM
Buffer now full DC3
Printhead hot SI
Label at strip pin FS
Label skipping DC1
Ready DC1
Printing DC1
