Appendix B — Media Specifications
76 EasyCoder PD42 Printer User’s Guide
Tickets With Gaps
* This is the print length limit set by memory constraints.
Paper Type Setup
•Tickets with Gaps
a: Media Width
Maximum: 118.0 mm 4.65 inches
Minimum: 25.0 mm 1.00 inches
b: Copy Length Fingerprint IPL
8 dots/mm (203 dpi)
Maximum: 1270 mm (50 in.)* 600 mm (23 in.)
Minimum: 6 mm (0.2 in.) 6 mm (0.2 in.)
11.81 dots/mm (300 dpi)
Maximum: 558.8 mm (22 in.)* 406.4 mm (16 in.)
Minimum: 6 mm (0.2 in.) 6 mm (0.2 in.)
c: Detection Position
Variable: 0 to 57 mm 0 to 2.24 inches
d: Detection Slit Length
The length of the detection slit (excluding corner radius) must be
minimum 2.5 mm (0.10 inches) on either side of the detection
position.
e: Detection Slit Height
Maximum: 26.0 mm 1.02 inches
Minimum: 1.2 mm 0.05 inches
Recommended: 3.0 mm 0.12 inches
Note: Do not allow any perforation to break the edge
of the media as this may cause the media to split and
jam the printer.
