Chapter 2 — Installing the Printer
EasyCoder PD42 Printer User’s Guide 19
6 Reattach the front cover.
7 Push in on the lower part of the label-taken sensor and bring
it out to a fully horizontal position.
8 Close the side door.
9 Press the Print button to advance the media.
Loading Thermal Transfer Ribbon
Thermal transfer printing makes it possible to use a wide range of
receiving face materials and gives a durable printout that is less
vulnerable to fat, chemicals, heat, sunlight and so on than direct
thermal printing. Make sure to select a ribbon type that matches
the type of receiving material and set up the printer accordingly.
The ribbon is normally loaded at the same time as a new media
roll. For clarity, the following illustrations do not show the media
roll. See the previous sections for information on how to load
media for your type of operation.
