Appendix B — Media Specifications
78 EasyCoder PD42 Printer User’s Guide
Tickets With Black Mark
* This is the print length limit set by memory constraints.
Paper Type Setup
•Tickets with Mark
a: Media Width
Maximum: 118.0 mm 4.65 inches
Minimum: 25.0 mm 1.00 inches
b: Copy Length Fingerprint IPL
8 dots/mm (203 dpi)
Maximum: 1270 mm (50 in.)* 600 mm (23 in.)
Minimum: 6 mm (0.2 in.) 6 mm (0.2 in.)
11.81 dots/mm (300 dpi)
Maximum: 558.8 mm (22 in.)* 406.4 mm (16 in.)
Minimum: 6 mm (0.2 in.) 6 mm (0.2 in.)
c: Detection Position
Variable: 0 to 57 mm 0 to 2.24 inches
d: Black Mark Width
The detectable width of the black mark should be at least 5.0 mm (0.2
inches) on either side of the Label Gap Sensor detection point.
e: Black Mark Length
Maximum: 25.0 mm 0.98 inches
Minimum: 3 mm 0.12 inches
Common: 5 mm 0.2 inches
f: Black Mark Y-Position
It is recommended that you place the black mark as close to the front
edge of ticket as possible and use a negative Stop Adjust value to
control the media feed, so the tickets can be properly torn off.
