PM43 Service Work Instructions
PM43,PM43C
SWIPM43x-000
Page
24 of 70
Intermec Proprietary Document
Figure 4 – Guide, Media, Top, Dancer, Spare, Assembly Figure 5 - Dancer Assembly
Figure 6 - Sensor, LSS Upper Assembly, Spare
Figure 7 – Removing LSS Upper Assembly Figure 8 – Removing Dancer Assembly
1
2
Guide Posts
Guide Pin
Spring
3
