PM43 Service Work Instructions
PM43,PM43C
SWIPM43x-000
Page
38 of 70
Intermec Proprietary Document
OPERATION:
Back Plate
This is a NOT customer replaceable part.
Tools Required
Description
Part Number
Torx Driver
T10
Torx Driver
T20
Parts Required
Item
Part Number
Description
Qty
1
710-127S-001
Assembly, Cover, IO, Spare, PM43
1
710-149S-001
Assembly, Cover, IO, Spare, PM43c
1
2
710-103S-001
Assembly, Plate, Back, Spare, PM43
1
710-150S-001
Assembly, Plate, Back, Spare, PM43c
1
Back Plate Replacement
1. Procedure - TBA
2. Procedure - TBA
I/O Cover Replacement
1. Procedure - TBA
2. Procedure - TBA
1
2
