Intermec PM43 - Page 27

TITLE
Model
DOCUMENT NO.
PAGE
PM43 Service Work Instructions
PM43,PM43C
SWIPM43x-000
Page
27 of 70
Intermec Proprietary Document
Access Door Replacement PM43c
1. Remove the torx screw securing the access door. See Figure 2.
2. Slide the access door right and lift the door away from the bottom deck.
Figure 2
Access Door, PM43c
2
3
