Intermec PM43 Service Manual

TITLE
Model
DOCUMENT NO.
PAGE
PM43 Service Work Instructions
PM43,PM43C
SWIPM43x-000
Page
3 of 70
Intermec Proprietary Document
PM43 / PM43c LCD Touch Panel and Display Assembly ................................................................................................................. 44
PM43/PM43c Speaker .................................................................................................................................................................... 47
PM43/PM43c Full Touch & One Button (ICON) Overlays ............................................................................................................... 48
Exploded View - PM43 Electronics Section .................................................................................................................................... 49
Accessories Electronics - Interface and Radio Boards ..................................................................................................................... 49
Main Logic Board (MLB) Assembly .................................................................................................................................................. 50
Power Supply Electronics Assembly (Behind the MLB) ................................................................................................................... 52
D-Sub Wiring Cable ......................................................................................................................................................................... 54
Ribbon Take Up Gear Mechanism ................................................................................................................................................... 55
Front Panel I/O Cable (shown disconnected from the MLB) .......................................................................................................... 56
Kit, Service, Drive Pulley .................................................................................................................................................................. 57
Ribbon & Platen Motor w/Gears, Tensioner , and Drive Belts ....................................................................................................... 58
Internal Rewinder Mechanism ........................................................................................................................................................ 60
Rewinder Full Batch Take-UpAssembly ........................................................................................................................................... 66
Cutter Assembly .............................................................................................................................................................................. 67
Screws & Torque Settings ............................................................................................................................................................... 69
Print-On-Demand Label Printing System ........................................................................................................................................ 70
Testing ............................................................................................................................................................................................. 70

Intermec PM43 Specifications

General

Color	-
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Maximum printing width	108 mm
Ethernet LAN	Yes
Optional connectivity	Bluetooth, Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired
Certification	RoHS, CE (EN55022 Class A), FCC Class A, UL/cUL, D Mark and CCC
Internal memory	128 MB
Built-in barcodes	1D, 2D
Image formats supported	BMP, GIF, PCX, PNG
Page description languages	DP, DPL, IPL, XML, ZPL II
Display	LCD
Control type	Touch
Product color	Gray
PC connection	RS-232
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
AC input voltage	100 - 240 V
AC input frequency	45 - 65 Hz
Power consumption (standby)	9 W
Media thickness	3 - 10.4 mm
Maximum label width	114 mm
Maximum roll diameter	80 mm
Languages support	CHI (SIMPL), CHI (TR), DEU, ENG, ESP, FRE, ITA, KOR, POR, RUS
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	483.54 mm
Width	284.2 mm
Height	294.61 mm
Weight	15820 g
