Appendix — Specifications and Accessories

68 SR61T Tethered Scanner User’s Guide

EX25 Near-Far Range Area Imager (SR61TE)

Scan angles: 12.2° horizontal

7.8° vertical

14.4° diagonal

Light source angles: 13° horizontal

11° vertical

17° diagonal

Light source: 650 nm laser (aiming beam and auto focus)

617 nm highly visible LED (lighting system)

1D Symbologies Minimum Reading Distances With 0.325 cm (0.128) Setback

Symbology Density Minimum Distance Maximum Distance

Code 39 0.1 mm (3.8 mils)

0.25 mm (10 mils)

0.5 mm (20 mils)

1 mm (40 mils)

1.3 mm (51 mils)

2.5 mm (100 mils)

18 cm (7.09 in)

19 cm (7.48 in)

40 cm (15.75 in)

100 cm (39.37 in)

130 cm (51.18 in)

32 cm (12.60 in)

69 cm (27.16 in)

110 cm (43.31 in)

220 cm (86.61 in)

310 cm (122.05 in)

430 cm (169.29 in)

EAN 100% 0.33 mm 22 cm (7.87 in) 100 cm (39.37 in)

*Minimum reading distances are measured in the dark (0 lux).
