Interroll MultiControl User Manual

Interroll MultiControl
Assembly and installation
18 Version 2.3 (01/2017) en-US
Translation of original instruction manual
Warning notices concerning the electrical installation
Improper electrical installation can leads to damage of the MultiControl.
4 Only have an electrician undertake electrical installation work.
4 Observe national regulations for the electrical installation. Within the EU, IEC 60204-1 must
be adhered to at a minimum.
4 Before the installation, wiring or removal of the MultiControl, de-energize it and secure it
against inadvertent reactivation.
4 The MultiControl may be operated only with DC voltage with a rated voltage of 24V and a
maximum permissible deviation of ±5%.
4 The MultiControl may be operated only with a protected extra-low voltage (PELV according
to IEC 60204-1).
4 Never operate the MultiControl with AC voltage since this will lead to unrepairable damage
to the device.
4 When connecting the MultiControl, observe the correct polarity of the voltage supply.
Reversing the polarity leads to unrepairable damage to the device and the connected
motors.
4 Ensure that no hazardous voltage can come into contact with the connections or the housing,
not even in the event of a malfunction or fault.
4 Place all voltage supplies used on a common ground potential to avoid equalizing currents
via the MultiControl or the bus line.
4 Ensure that the RollerDrive, VDC motors and voltage sources connected with the
MultiControl, as well as the entire conveyor system, are correctly grounded. Incorrect
grounding can result in the build-up of static charge, causing the MultiControl to malfunction
or fail prematurely.
4 Ensure that the existing electrical installation has no interfering effect on the MultiControl.
4 Use only cables that are sufficiently dimensioned for the specific operating conditions.
4 Do not forget to observe the calculations for voltage drop on electrical lines.
4 Observe the regulations for routing cables.
4 Use suitable switching equipment and protective devices to ensure safe operation.
4 Only apply operating voltages when all of the cables have been connected.
4 Do not apply too much tension or load to the plug. When bending the cable at the plug, the
insulation of the cable could be damaged and the MultiControl could fail.

Interroll MultiControl Specifications

General

Power Supply	24 VDC
Rated Voltage	24 VDC
Storage Temperature	-20 °C to +70 °C
Communication Protocols	Ethernet/IP, PROFINET, EtherCAT, CANOpen
Number of Channels	4
Weight	0.5 kg
