Page #40 background imageLoading...
Page #40 background image
Interroll MultiControl
Troubleshooting
40 Version 2.3 (01/2017) en-US
Translation of original instruction manual
LEDs of connections
LED State Meaning
Sensor 1
Sensor 2
Sensor 3
Sensor 4
On Logical switching state of displayed sensor:
Positive logic configured and logical "1" (PNP 24 V, NPN 0 V) at
input
- or -
Negative logic configured and logical "0" at input
I/O 1
I/O 2
I/O 3
I/O 4
On Logical switching state of displayed input/output:
Positive logic configured and logical "1" (PNP 24 V, NPN 0 V) at
input
- or -
Negative logic configured and logical "0" at input
RD 1
RD 2
RD 3
RD 4
On Displayed RollerDrive receives nominal value
Link A
Link B
On or
flashing
(for EtherCat
bus type)
Displayed network connection is OK
