Appendix
Accessories
Designation Reference number
Cable bridge S-1004028
Flat cable for voltage
(3G3G-FL, 2 x 2.5 mm², black, 25-m sections)
S-1004030
400-V power supply S-1004029
Magnetic key S-64100210
Y-line 3-pin S-1104439
Y-line 4-pin S-1104460
EtherNet line M12/M12 (3 m) S-1104438
MultiControl enclosure:
1 x M12 dummy plug
3 x M8 Snap-in dummy plug
3 x M8 screw connection dummy plug
S-1104466
Extension cable for RollerDrive EC310, (2 m) S-1004033
Data types
The following data types are used for cyclical and acyclical communication with the MultiControl:
Abbreviatio
n
Data type Description
BOOL Boolean Truth value (true/false)
BYTE Byte Bit sequence with 8 bits
SINT Short Integer Integer variable with 8 bit
USINT Unsigned Short Integer Positive integer variable with 8 bit
INT Integer Integer variable with 16 bit
UINT Unsigned Integer Positive integer variable with 16 bit
DINT Double Integer Integer variable with 32 bit
UDINT Unsigned Double Integer Positive integer variable with 32 bit
LINT Long Integer Integer variable with 64 bit
STRING String Character string with up to 31 characters

Interroll MultiControl Specifications

General

Power Supply	24 VDC
Rated Voltage	24 VDC
Storage Temperature	-20 °C to +70 °C
Communication Protocols	Ethernet/IP, PROFINET, EtherCAT, CANOpen
Number of Channels	4
Weight	0.5 kg
