Interroll MultiControl
Version 2.3 (01/2017) en-US
Translation of original instruction manual
23
Initial startup and operation
Checks before initial startup
4 Ensure that the base plate of the MultiControl is correctly fastened to the profile, that the
MultiControl is correctly fastened to the base plate, and that all screws are properly
tightened.
4 Ensure that there are no additional areas of danger caused by interfaces to other
components.
4 Ensure that the wiring is in accordance with the specification and legal directives.
4 Check all protection devices.
4 Ensure there are no bystanders in dangerous areas around the conveyor.
Configuration options
To start up the MultiControl, it has to be configured first. There are several ways to achieve this:
• All settings can be configured using a web-based user interface on a computer connected to
the MultiControl (see "User interface", page24).
• All settings, except for the bus type, can be configured using Service Data Objects (SDO)
that are written by a master controller (see "Service Data Objects (SDO)", page25).
• With the help of the magnetic sensor, the bus type and LED indicators can be configured
directly on the MultiControl and the MultiControl can be tested, automatically configured or
reset to factory settings (see "Magnetic sensor", page25).
• With a PLC development environment, the station name, IP configuration and connection
settings can be changed.
