User interface
The MultiControl features an integrated web server generating a user interface for configuring
the MultiControl. This user interface can be called up in a web browser on a computer
connected to the MultiControl. Except for a web browser, no other software has to be installed
on the computer.
Prerequisites
The following requirements must be met to be able to use the web-based user interface:
• The MultiControl features a valid IP address that is known (delivery state: IP address
192.168.0.1, subnet mask 255.255.255.0).
• An Ethernet connection exists between MultiControl and computer.
• Access to port 80 is possible (user interface is HTTP-based).
• MultiControl is not configured to EtherCAT since EtherCAT does not allow HTTP
communication. The bus type can be read using the magnetic sensor, see "Magnetic sensor",
page25.
Starting the user interface
4 Start the web browser on the computer connected with MultiControl.
4 On the address line, enter the IP address of MultiControl (delivery state:
http://192.168.0.1/).
4 Enter the login data on the login page.
(delivery state: User name "Interroll", password "Interroll")
The start screen appears.
The left side shows the navigation menu which always remains the same. The right side shows
the respective information part.
4 To end your work, click on "Log Out" (not necessary if MultiControl is being restarted).
