Interroll MultiControl
Appendix
Version 2.3 (01/2017) en-US
Translation of original instruction manual
57
I/O configuration
No. Value Designation Comment
1 0 None I/O not used
2 1 PLC Input Input signal to PLC
3 2 PLC Output Output signal from PLC
4 15 Sensor 5 Additional inputs can also be found at the
corresponding point in the process image.
5 16 Sensor 6
6 17 Sensor 7
7 18 Sensor 8
8 21 Control Input 1
9 22 Control Input 2
10 23 Control Input 3
11 24 Control Input 4
12 25 Control Input 5
13 26 Control Input 6
14 27 Control Input 7
15 28 Control Input 8
16 31 Control Output 1
17 32 Control Output 2
18 33 Control Output 3
19 34 Control Output 4
20 35 Control Output 5
21 36 Control Output 6
22 37 Control Output 7
23 38 Control Output 8
24 41 Handshake InUp
25 42 Handshake InDown
26 43 Handshake InSide 1
27 44 Handshake InSide 2
28 45 Handshake OutUp
29 46 Handshake OutDown
30 47 Handshake OutSide 1
31 48 Handshake OutSide 2
32 51 StartGlobalDirect
33 52 StartGlobalInvers
34 53 StopGlobalDirect
