Interroll MultiControl User Manual

Interroll MultiControl
Appendix
Version 2.3 (01/2017) en-US
Translation of original instruction manual
55
LED indicators
SDO index: 0x4800
Subindex Designation Data type Access Comment
15 IO Diagnose LED On BOOL R/W TRUE: LED on
FALSE: LED off
Application module
SDO index: 0x4900
Subindex Designation Data type Access Comment
1 State Table ID UINT R/W
2 Timer 1 UINT R/W I/O device application program: Without effect
Other application programs: Setting according to description
3 Timer 2 UINT R/W
4 Timer 3 UINT R/W
5 Timer 4 UINT R/W

Interroll MultiControl Specifications

General

Power Supply	24 VDC
Rated Voltage	24 VDC
Storage Temperature	-20 °C to +70 °C
Communication Protocols	Ethernet/IP, PROFINET, EtherCAT, CANOpen
Number of Channels	4
Weight	0.5 kg
