Interroll MultiControl
Appendix
52 Version 2.3 (01/2017) en-US
Translation of original instruction manual
Bus parameters
SDO index: 0x4600
Subindex Designation Data type Access Comment
1 Bus Type USINT R Bus type used:
1 = EtherCAT
2 = PROFINET
3 = EtherNet/IP
2 IP Configuration Mode USINT R/W Configuration mode of the address:
1 = Static
2 = BOOTP
3 = DHCP
3 IP Address UDINT R/W Own IP address
4 IP Network Mask UDINT R/W Subnet mask
5 IP Gateway Address UDINT R/W IP Address Default Gateway
6 IP Address DNS 1 UDINT R/W IP Address Domain Name Server #1
7 IP Address DNS 2 UDINT R/W IP Address Domain Name Server #2
8 IP Host Name STRING R/W IP Host Name
9 IP Domain Name STRING R/W IP Domain Name
A ACD Enable BOOL R/W Recognition of address conflicts (EtherNet/IP)
B Quick Startup Enable BOOL R/W Quickstart (PROFINET)
C IP Address Neighbor 1 UDINT R/W IP address of neighbors when using ZPA and ZPA+.
D IP Address Neighbor 2 UDINT R/W
S IP Address Neighbor 3 UDINT R/W
F IP Address Neighbor 4 UDINT R/W
10 IP Address Neighbor 5 UDINT R/W
11 IP Address Neighbor 6 UDINT R/W
12 IP Address Neighbor 7 UDINT R/W
13 IP Address Neighbor 8 UDINT R/W
14 Big Endian format: BOOL R/W PLC data are in big endian format (MSB first)
