Goodrive350 IP55 High-ingress Protection Series VFD Function parameter list
-143-
voltage of motor 1)
Setting range of P04.05: P04.03–P04.07
Setting range of P04.06: 0.0%–110.0% (rated
voltage of motor 1)
Setting range of P04.07: P04.05–P02.02 (rated
frequency of motor 1) or P04.05–P02.16 (rated
frequency of motor 1)
Setting range of P04.08: 0.0%–110.0% (rated
voltage of motor 1)
V/F slip
compensation
gain of motor 1
This function code is used to compensate for the
motor speed changes occurred during load
variation in SVPWM control mode, thus
improving the rigidity of mechanical
characteristics of motor. Rated slip frequency of
the motor should be calculated.
△f=fb-n×p/60
of which: fb is rated motor frequency,
corresponds to P02.02; n is rated motor speed,
corresponds to P02.03; p is the number of motor
pole pairs. 100% corresponds to the rated slip
frequency of motor â–³f.
Setting range: 0.0–200.0%
Low-frequency
oscillation
control factor of
motor 1
Under SVPWM control mode, the motor,
especially the large-power motor may
experience current oscillation during certain
frequencies, which may lead to unstable motor
operation, or even VFD overcurrent, users can
adjust these two parameters properly to
eliminate such phenomenon.
Setting range of P04.10: 0–100
Setting range of P04.11: 0–100
Setting range of P04.12: 0.00Hz–P00.03 (max.
output frequency)
High-frequency
oscillation
control factor of
motor 1
Oscillation
control threshold
of motor 1
V/F curve setup
of motor 2
0: Straight V/F curve;
1: Multi-point V/F curve
2: Torque-down V/F curve (power of 1.3)
3: Torque-down V/F curve (power of 1.7)
4: Torque-down V/F curve (power of 2.0)
5: Customize V/F (V/F separation)
0.0%: (automatic) 0.1%–10.0%
Motor 2 torque
boost cut-off
0.0%–50.0% (relative to rated frequency of
motor 2)
V/F frequency
point 1 of motor
2
