Goodrive350 IP55 High-ingress Protection Series VFD Function parameter list
-169-
Function
code
Name
Description
Default
value
Modify
P08.40
PWM selection
0x0000–0x1121
Ones place: PWM mode selection
0: PWM mode 1, 3PH modulation and 2PH
modulation
1: PWM mode 2, 3PH modulation
Tens place: PWM low-speed carrier limit
0: Low-speed carrier limit mode 1
1: Low-speed carrier limit mode 2
2: No limit
Hundreds place: Deadzone compensation
method
0: Compensation method 1
1: Compensation method 2
Thousands place: PWM loading mode selection
0: Interruptive loading
1: Normal loading
0x1101
◎
P08.41
Overmodulation
selection
0x0000–0x1111
Ones place:
0: Disable overmodulation
1: Enable overmodulation
Tens place
0: Mild overmodulation
1: Deepened overmodulation
Hundreds: Carrier frequency limit
0: Yes
1: No
Thousands: Output voltage compensation
0: No
1: Yes
0X1001
◎
P08.42
Reserved
/
/
/
P08.43
Reserved
/
/
/
P08.44
UP/DOWN
terminal control
setup
0x000–0x221
Ones: Frequency control selection
0: UP/DOWN terminal setup is valid
1: UP/DOWN terminal setup is invalid
Tens: Frequency control selection
0: Valid only when P00.06=0 or P00.07=0
1: All frequency modes are valid
2: Invalid for multi-step speed when multi-step
speed takes priority
Hundreds: Action selection during stop
0: Valid
1: Valid during running, clear after stop
2: Valid during running, clear after receiving stop
command
0x000
○
