INVT Goodrive350 IP55

Goodrive350 IP55 High-ingress Protection Series VFD Function parameter list
-178-
Function
code
Name
Description
Default
value
Modify
of step 13
Step
0
1
2
3
4
5
6
7
T1
OFF
ON
OFF
ON
OFF
ON
OFF
ON
T 2
OFF
OFF
ON
ON
OFF
OFF
ON
ON
T3
OFF
OFF
OFF
OFF
ON
ON
ON
ON
T4
ON
ON
ON
ON
ON
ON
ON
ON
Step
8
9
10
11
12
13
14
15
P10.30
Multi-step
speed 14
0.0%
○
P10.31
Running time
of step 14
0.0s(min)
○
P10.32
Multi-step
speed 15
0.0%
○
P10.33
Running time
of step 15
0.0s(min)
○
P10.34
Acceleration/d
eceleration
time of step 0
–7 of simple
PLC
Detailed illustration is shown in the table below.
Function
code
Binary
Step
ACC/
DEC
time 1
ACC/
DEC
time 2
ACC/
DEC
time 3
ACC/
DEC
time 4
P10.34
BIT1
BIT0
0
00
01
10
11
BIT3
BIT2
1
00
01
10
11
BIT5
BIT4
2
00
01
10
11
BIT7
BIT6
3
00
01
10
11
BIT9
BIT8
4
00
01
10
11
BIT11
BIT10
5
00
01
10
11
BIT13
BIT12
6
00
01
10
11
BIT15
BIT14
7
00
01
10
11
P10.35
BIT1
BIT0
8
00
01
10
11
BIT3
BIT2
9
00
01
10
11
BIT5
BIT4
10
00
01
10
11
BIT7
BIT6
11
00
01
10
11
BIT9
BIT8
12
00
01
10
11
BIT11
BIT10
13
00
01
10
11
BIT13
BIT12
14
00
01
10
11
BIT15
BIT14
15
00
01
10
11
Select corresponding acceleration/deceleration
time, and then convert 16-bit binary number into
hexadecimal number, finally, set corresponding
function code.
Acceleration/deceleration time 1 is set by P00.11
and P00.12; Acceleration/deceleration time 2 is set
by P08.00 and P08.01; Acceleration/deceleration
time 3 is set by P08.02 and P08.03; Acceleration
/deceleration time 4 is set by P08.04 and P08.05.
Setting range: 0x0000–0xFFFF
0x0000
○
P10.35
Acceleration/d
eceleration
time of step 8
– 15 of simple
PLC
0x0000
○
P10.36
PLC restart
mode
0: Restart from the first step, namely if the VFD
stops during running (caused by stop command,
fault or power down), it will run from the first step
after restart.
1: Continue running from the step frequency when
interruption occurred, namely if the VFD stops
0
◎
